Most antibiotics work by interfering with critical functions such as DNA replication or construction of the bacterial cell wall. However, these mechanisms represent only part of the full picture of how antibiotics act.
In a new study of antibiotic action, MIT researchers developed a new machine-learning approach to discover an additional mechanism that helps some antibiotics kill bacteria. This secondary mechanism involves activating the bacterial metabolism of nucleotides that the cells need to replicate their DNA.
“There are dramatic energy demands placed on the cell as a result of the drug stress. These energy demands require a metabolic response, and some of the metabolic byproducts are toxic and help contribute to killing the cells,” says James Collins, the Termeer Professor of Medical Engineering and Science in MIT’s Institute for Medical Engineering and Science (IMES) and Department of Biological Engineering, and the senior author of the study. Collins is also the faculty co-lead of the Abdul Latif Jameel Clinic for Machine Learning in Health.
Exploiting this mechanism could help researchers to discover new drugs that could be used along with antibiotics to enhance their killing ability, the researchers say.
Jason Yang, an IMES research scientist, is the lead author of the paper, which appears in the May 9 issue of Cell. Other authors include Sarah Wright, a recent MIT MEng recipient; Meagan Hamblin, a former Broad Institute research technician; Miguel Alcantar, an MIT graduate student; Allison Lopatkin, an IMES postdoc; Douglas McCloskey and Lars Schrubbers of the Novo Nordisk Foundation Center for Biosustainability; Sangeeta Satish and Amir Nili, both recent graduates of Boston University; Bernhard Palsson, a professor of bioengineering at the University of California at San Diego; and Graham Walker, an MIT professor of biology.
Collins and Walker have studied the mechanisms of antibiotic action for many years, and their work has shown that antibiotic treatment tends to create a great deal of cellular stress that makes huge energy demands on bacterial cells. In the new study, Collins and Yang decided to take a machine-learning approach to investigate how this happens and what the consequences are.
Before they began their computer modeling, the researchers performed hundreds of experiments in E. coli. They treated the bacteria with one of three antibiotics — ampicillin, ciprofloxacin, or gentamicin, and in each experiment, they also added one of about 200 different metabolites, including an array of amino acids, carbohydrates, and nucleotides (the building blocks of DNA). For each combination of antibiotics and metabolites, they measured the effects on cell survival.
“We used a diverse set of metabolic perturbations so that we could see the effects of perturbing nucleotide metabolism, amino acid metabolism, and other kinds of metabolic subnetworks,” Yang says. “We wanted to fundamentally understand which previously undescribed metabolic pathways might be important for us to understand how antibiotics kill.”
Many other researchers have used machine-learning models to analyze data from biological experiments, by training an algorithm to generate predictions based on experimental data. However, these models are typically “black-box,” meaning that they don’t reveal the mechanisms that underlie their predictions.
To get around that problem, the MIT team took a novel approach that they call “white-box” machine-learning. Instead of feeding their data directly into a machine-learning algorithm, they first ran it through a genome-scale computer model of E. coli metabolism that had been characterized by Palsson’s lab. This allowed them to generate an array of “metabolic states” described by the data. Then, they fed these states into a machine-learning algorithm, which was able to identify links between the different states and the outcomes of antibiotic treatment.
Have you read?
Because the researchers already knew the experimental conditions that produced each state, they were able to determine which metabolic pathways were responsible for higher levels of cell death.
“What we demonstrate here is that by having the network simulations first interpret the data and then having the machine-learning algorithm build a predictive model for our antibiotic lethality phenotypes, the items that get selected by that predictive model themselves directly map onto pathways that we’ve been able to experimentally validate, which is very exciting,” Yang says.
Markus Covert, an associate professor of bioengineering at Stanford University, says the study is an important step toward showing that machine learning can be used to uncover the biological mechanisms that link inputs and outputs.
“Biology, especially for medical applications, is all about mechanism,” says Covert, who was not involved in the research. “You want to find something that is druggable. For the typical biologist, it hasn’t been meaningful to find these kinds of links without knowing why the inputs and outputs are linked.”
This model yielded the novel discovery that nucleotide metabolism, especially metabolism of purines such as adenine, plays a key role in antibiotics’ ability to kill bacterial cells. Antibiotic treatment leads to cellular stress, which causes cells to run low on purine nucleotides. The cells’ efforts to ramp up production of these nucleotides, which are necessary for copying DNA, boost the cells’ overall metabolism and leads to a buildup of harmful metabolic byproducts that can kill the cells.
“We now believe what’s going on is that in response to this very severe purine depletion, cells turn on purine metabolism to try to deal with that, but purine metabolism itself is very energetically expensive and so this amplifies the energic imbalance that the cells are already facing,” Yang says.
The findings suggest that it may be possible to enhance the effects of some antibiotics by delivering them along with other drugs that stimulate metabolic activity. “If we can move the cells to a more energetically stressful state, and induce the cell to turn on more metabolic activity, this might be a way to potentiate antibiotics,” Yang says.
The “white-box” modeling approach used in this study could also be useful for studying how different types of drugs affect diseases such as cancer, diabetes, or neurodegenerative diseases, the researchers say. They are now using a similar approach to study how tuberculosis survives antibiotic treatment and becomes drug-resistant.
The research was funded by the Defense Threat Reduction Agency, the National Institutes of Health, the Novo Nordisk Foundation, the Paul G. Allen Frontiers Group, the Broad Institute of MIT and Harvard, and the Wyss Institute for Biologically Inspired Engineering.
